BITOLA
ACIMA DE 30MM
SOB-CONSULTA E LOTE MÍNIMO
|
| DIMENSÕES |
CAPAC. DE CARGA |
PESO |
DESIGNAÇÃO
|
| DINÂM. |
ESTÁT |
| D1 |
D2 |
B1 |
B2 |
L1 |
L2 |
|
R |
kgf |
Kgf |
grs. |
| 05 |
18 |
6 |
4 |
33 |
19 |
12 |
M 5x0,8 |
370 |
555 |
0.019 |
FMSED 05 EST |
| 06 |
20 |
6 |
4 |
36 |
21 |
12 |
M 6x1,0 |
370 |
555 |
0.020 |
FMSED 06 EST |
| 08 |
24 |
8 |
6 |
42 |
22 |
11 |
M 8x1,25 |
593 |
890 |
0.031 |
FMSED 08 EST |
| 10 |
30 |
9 |
7 |
48 |
26 |
8 |
M 10x1,5 |
880 |
1.300 |
0.053 |
FMSED 10 EST |
| 12 |
34 |
10 |
8 |
54 |
28 |
6 |
M 12x1,75 |
1.700 |
1.800 |
0.088 |
FMSED 12 EST |
| 15 |
40 |
12 |
10 |
63 |
34 |
6 |
M 14x2,0 |
1.800 |
2.700 |
0.130 |
FMSED 15 EST |
| 17 |
42 |
14 |
11 |
68 |
36 |
8 |
M 16x2,0 |
2.300 |
3.500 |
0.200 |
FMSED 17 EST |
| 20 |
50 |
16 |
13 |
78 |
43 |
6 |
M 20x1,5 |
3.250 |
4.875 |
0.310 |
FMSED 20 EST |
| 25 |
62 |
20 |
17 |
94 |
53 |
5 |
M 24x2,0 |
5.200 |
7.800 |
0.570 |
FMSED 25 EST |
| 30 |
73 |
22 |
19 |
110 |
65 |
5 |
M 30x2,0 |
6.700 |
10.000 |
0.900 |
FMSED 30 EST |
| 35 |
82 |
25 |
21 |
140 |
82 |
7 |
M 36x3,0 |
8.650 |
13.000 |
1.400 |
FMSED 35 EST |
| 40 |
92 |
28 |
23 |
150 |
86 |
7 |
M 39x3,0 |
10.800 |
16.000 |
1.850 |
FMSED 40 EST |
| 45 |
102 |
32 |
27 |
163 |
94 |
7 |
M 42x3,0 |
13.800 |
20.700 |
2.550 |
FMSED 45 EST |
| 50 |
112 |
35 |
30 |
195 |
110 |
7 |
M 45x3,0 |
17.000 |
25.500 |
3.550 |
FMSED 50 EST |
| 60 |
135 |
44 |
38 |
210 |
115 |
8 |
M 52x3,0 |
26.500 |
39.800 |
5.700 |
FMSED 60 EST |
| 70 |
160 |
49 |
42 |
235 |
125 |
6 |
M 56x4,0 |
34.000 |
51.000 |
7.900 |
FMSED 70 EST |
| 80 |
180 |
55 |
47 |
270 |
140 |
6 |
M 64x4,0 |
43.200 |
64.800 |
12.000 |
FMSED 80 EST |
|
