| DIMENSÕES |
CAPAC.
DE CARGA |
PESO |
DESIGNAÇÃO
|
DINÂM. |
ESTÁT |
|
D1 |
D2 |
B1 |
B2 |
L1 |
L2 |
|
R |
kgf |
Kgf |
grs. |
05 |
18 |
8 |
6,0 |
33 |
19 |
13 |
M
5x0,8 |
332 |
475 |
0.016 |
FMSED
05 LB |
06 |
20 |
9 |
6,8 |
36 |
21 |
13 |
M
6x1,0 |
430 |
520 |
0.025 |
FMSED
06 LB |
08 |
24 |
12 |
9,0 |
42 |
25 |
14 |
M
8x1,25 |
725 |
830 |
0.043 |
FMSED
08 LB |
10 |
30 |
14 |
10,5 |
48 |
28 |
13 |
M
10x1,5 |
1.000 |
1.280 |
0.072 |
FMSED
10 LB |
12 |
34 |
16 |
12,0 |
54 |
32 |
15 |
M
12x1,75 |
1.350 |
2.040 |
0.100 |
FMSED
12 LB |
14 |
36 |
19 |
13,5 |
60 |
36 |
16 |
M
14x2,0 |
1.700 |
2.700 |
0.160 |
FMSED
14 LB |
16 |
42 |
21 |
15,0 |
66 |
37 |
15 |
M
16x2,0 |
2.200 |
3.500 |
0.210 |
FMSED
16 LB |
18 |
46 |
23 |
16,5 |
72 |
41 |
15 |
M
18x1,5 |
2.650 |
4.400 |
0.300 |
FMSED
18 LB |
20 |
50 |
25 |
18,0 |
78 |
45 |
14 |
M
20x1,5 |
3.150 |
5.000 |
0.380 |
FMSED
20 LB |
22 |
54 |
28 |
20,0 |
84 |
48 |
15 |
M
22x1,5 |
3.800 |
6.700 |
0.500 |
FMSED
22 LB |
25 |
62 |
31 |
22,0 |
94 |
55 |
15 |
M
24x2,0 |
4.750 |
7.600 |
0.650 |
FMSED
25 LB |
30 |
73 |
37 |
25,0 |
110 |
66 |
17 |
M
30x2,0 |
6.40 |
10.400 |
1.000 |
FMSED
30 LB |
BITOLAS EM POLEGADAS
|
3/16" |
18 |
5/16 |
6,0 |
33 |
19 |
13 |
10
- 32 |
332 |
475 |
0.016 |
FMSED
3/16" LB |
1/4" |
20 |
3/8 |
6,8 |
36 |
21 |
13 |
1/4"
- 28 |
430 |
520 |
0.025 |
FMSED
1/4" LB |
5/16" |
24 |
7/16 |
9,0 |
42 |
25 |
14 |
5/16"
- 24 |
725 |
830 |
0.043 |
FMSED
5/16" LB |
3/8" |
30 |
1/2 |
10,5 |
48 |
28 |
13 |
3/8"
- 24 |
1.000 |
1.280 |
0.072 |
FMSED
3/8" LB |
7/16" |
34 |
5/8 |
12,0 |
54 |
32 |
15 |
7/16"
- 20 |
1.350 |
2.040 |
0.100 |
FMSED
7/16" LB |
1/2" |
34 |
5/8 |
12,0 |
54 |
32 |
15 |
1/2"
- 20 |
1.350 |
2.040 |
0.100 |
FMSED
1/2" LB |
5/8" |
42 |
3/4 |
15,0 |
66 |
37 |
15 |
5/8"
- 18 |
2.200 |
3.500 |
0.210 |
FMSED
5/8" LB |
3/4" |
50 |
1" |
18,0 |
78 |
45 |
14 |
3/4"
- 16 |
2.650 |
4.400 |
0.300 |
FMSED
3/4" LB |
|
